Kubernetes 部署 MySQL 高可用读写分离

来源：SegmentFault 2023-02-22 21:27:02 0浏览收藏

大家好，今天本人给大家带来文章《Kubernetes 部署 MySQL 高可用读写分离》，文中内容主要涉及到容器、MySQL、docker、Linux、kubernetes，如果你对数据库方面的知识点感兴趣，那就请各位朋友继续看下去吧~希望能真正帮到你们，谢谢！

Kubernetes 部署 MySQL 集群

简介： 在有状态应用中，MySQL是我们最常见也是最常用的。本文我们将实战部署一个一组多从的MySQL集群。

一、配置准备

configMap

cat > mysql-configmap.yaml

configMap可以将配置文件和镜像解耦开。
上面的配置意思是，创建一个master.cnf文件配置内容为：log-bin，即开启bin-log日志，供主节点使用。
创建一个slave.cnf文件配置内容为：super-read-only，设为该节点只读，供备用节点使用。

service

cat > mysql-services.yaml

StatefulSet

apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: mysql
spec:
  selector:
    matchLabels:
      app: mysql
  serviceName: mysql
  replicas: 3
  template:
    metadata:
      labels:
        app: mysql
    spec:
      # 设置初始化容器，进行一些准备工作
      initContainers:
      - name: init-mysql
        image: mysql:5.7
        # 为每个MySQL节点配置service-id
        # 如果节点序号是0，则使用master的配置， 其余节点使用slave的配置
        command:
        - bash
        - "-c"
        - |
          set -ex
          # 基于 Pod 序号生成 MySQL 服务器的 ID。
          [[ `hostname` =~ -([0-9]+)$ ]] || exit 1
          ordinal=${BASH_REMATCH[1]}
          echo [mysqld] > /mnt/conf.d/server-id.cnf
          # 添加偏移量以避免使用 server-id=0 这一保留值。
          echo server-id=$((100 + $ordinal)) >> /mnt/conf.d/server-id.cnf
          # Copy appropriate conf.d files from config-map to emptyDir.
          # 将合适的 conf.d 文件从 config-map 复制到 emptyDir。
          if [[ $ordinal -eq 0 ]]; then
            cp /mnt/config-map/master.cnf /mnt/conf.d/
          else
            cp /mnt/config-map/slave.cnf /mnt/conf.d/
          fi
        volumeMounts:
        - name: conf
          mountPath: /mnt/conf.d
        - name: config-map
          mountPath: /mnt/config-map
      - name: clone-mysql
        image: registry.cn-hangzhou.aliyuncs.com/chenby/xtrabackup:1.0
        # 为除了节点序号为0的主节点外的其它节点，备份前一个节点的数据
        command:
        - bash
        - "-c"
        - |
          set -ex
          # 如果已有数据，则跳过克隆。
          [[ -d /var/lib/mysql/mysql ]] && exit 0
          # 跳过主实例（序号索引 0）的克隆。
          [[ `hostname` =~ -([0-9]+)$ ]] || exit 1
          ordinal=${BASH_REMATCH[1]}
          [[ $ordinal -eq 0 ]] && exit 0
          # 从原来的对等节点克隆数据。
          ncat --recv-only mysql-$(($ordinal-1)).mysql 3307 | xbstream -x -C /var/lib/mysql
          # 准备备份。
          xtrabackup --prepare --target-dir=/var/lib/mysql
        volumeMounts:
        - name: data
          mountPath: /var/lib/mysql
          subPath: mysql
        - name: conf
          mountPath: /etc/mysql/conf.d
      containers:
      - name: mysql
        image: mysql:5.7
        # 设置支持免密登录
        env:
        - name: MYSQL_ALLOW_EMPTY_PASSWORD
          value: "1"
        ports:
        - name: mysql
          containerPort: 3306
        volumeMounts:
        - name: data
          mountPath: /var/lib/mysql
          subPath: mysql
        - name: conf
          mountPath: /etc/mysql/conf.d
        resources:
          # 设置启动pod需要的资源，官方文档上需要500m cpu，1Gi memory。
          # 我本地测试的时候，会因为资源不足，报1 Insufficient cpu, 1 Insufficient memory错误，所以我改小了点
          requests:
            # m是千分之一的意思，100m表示需要0.1个cpu
            cpu: 1024m
            # Mi是兆的意思，需要100M 内存
            memory: 1Gi
        livenessProbe:
          # 使用mysqladmin ping命令，对MySQL节点进行探活检测
          # 在节点部署完30秒后开始，每10秒检测一次，超时时间为5秒
          exec:
            command: ["mysqladmin", "ping"]
          initialDelaySeconds: 30
          periodSeconds: 10
          timeoutSeconds: 5
        readinessProbe:
          # 对节点服务可用性进行检测， 启动5秒后开始，每2秒检测一次，超时时间1秒
          exec:
            # 检查我们是否可以通过 TCP 执行查询（skip-networking 是关闭的）。
            command: ["mysql", "-h", "127.0.0.1", "-e", "SELECT 1"]
          initialDelaySeconds: 5
          periodSeconds: 2
          timeoutSeconds: 1
      - name: xtrabackup
        image: registry.cn-hangzhou.aliyuncs.com/chenby/xtrabackup:1.0
        ports:
        - name: xtrabackup
          containerPort: 3307
        # 开始进行备份文件校验、解析和开始同步
        command:
        - bash
        - "-c"
        - |
          set -ex
          cd /var/lib/mysql
          # 确定克隆数据的 binlog 位置（如果有的话）。
          if [[ -f xtrabackup_slave_info && "x$(<xtrabackup_slave_info then xtrabackup master to cat xtrabackup_slave_info sed> change_master_to.sql.in
            # 在这里要忽略 xtrabackup_binlog_info （它是没用的）。
            rm -f xtrabackup_slave_info xtrabackup_binlog_info
          elif [[ -f xtrabackup_binlog_info ]]; then
            # 我们直接从主实例进行克隆。解析 binlog 位置。
            [[ `cat xtrabackup_binlog_info` =~ ^(.*?)[[:space:]]+(.*?)$ ]] || exit 1
            rm -f xtrabackup_binlog_info xtrabackup_slave_info
            echo "CHANGE MASTER TO MASTER_LOG_FILE='${BASH_REMATCH[1]}',\
                  MASTER_LOG_POS=${BASH_REMATCH[2]}" > change_master_to.sql.in
          fi
          # 检查我们是否需要通过启动复制来完成克隆。
          if [[ -f change_master_to.sql.in ]]; then
            echo "Waiting for mysqld to be ready (accepting connections)"
            until mysql -h 127.0.0.1 -e "SELECT 1"; do sleep 1; done
            echo "Initializing replication from clone position"
            mysql -h 127.0.0.1 \
                  -e "$(<change_master_to.sql.in master_host="mysql-0.mysql" master_user="root" master_password="" master_connect_retry="10;" start slave exit mv change_master_to.sql.in change_master_to.sql.orig fi exec ncat volumemounts: name: data mountpath: subpath: mysql conf resources: requests: cpu: memory: volumes: emptydir: config-map configmap: volumeclaimtemplates: metadata: annotations: volume.beta.kubernetes.io nfs-storage spec: accessmodes: storage:></change_master_to.sql.in></xtrabackup_slave_info>

二、创建所需资源

# 创建configMap
kubectl apply -f  mysql-configmap.yaml
# 创建service
kubectl apply -f  mysql-services.yaml
# 创建statefulSet
kubectl apply -f  mysql-statefulset.yaml

# 查看创建过程
kubectl get pods --watch

mysql-0                                   0/2     Pending   0             0s
mysql-0                                   0/2     Pending   0             0s
mysql-0                                   0/2     Init:0/2   0             0s
mysql-0                                   0/2     Init:0/2   0             1s
mysql-0                                   0/2     Init:1/2   0             2s
mysql-0                                   0/2     PodInitializing   0             3s
mysql-0                                   1/2     Running           0             4s
mysql-0                                   2/2     Running           0             8s
mysql-1                                   0/2     Pending           0             0s
mysql-1                                   0/2     Pending           0             0s
mysql-1                                   0/2     Init:0/2          0             0s
mysql-1                                   0/2     Init:0/2          0             1s
mysql-1                                   0/2     Init:1/2          0             1s
mysql-1                                   0/2     PodInitializing   0             2s
mysql-1                                   1/2     Running           0             3s
mysql-1                                   2/2     Running           0             8s
mysql-2                                   0/2     Pending           0             0s
mysql-2                                   0/2     Pending           0             0s
mysql-2                                   0/2     Init:0/2          0             0s
mysql-2                                   0/2     Init:0/2          0             1s
mysql-2                                   0/2     Init:1/2          0             2s
mysql-2                                   0/2     PodInitializing   0             3s
mysql-2                                   1/2     Running           0             4s
mysql-2                                   2/2     Running           0             9s

三、测试主库

进入pod进行操作

# 进入到pod mysql-0中，进行测试

kubectl exec -it mysql-0 bash

# 用mysql-client链接mysql-0

mysql -h mysql-0
Welcome to the MySQL monitor.  Commands end with ; or \g.
Your MySQL connection id is 276
Server version: 5.7.38-log MySQL Community Server (GPL)

Copyright (c) 2000, 2022, Oracle and/or its affiliates.

Oracle is a registered trademark of Oracle Corporation and/or its
affiliates. Other names may be trademarks of their respective
owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

mysql>

创建库、表

# 创建数据库test
mysql> create database cby;
Query OK, 1 row affected (0.00 sec)

# 使用test库
mysql> use cby;
Database changed

# 创建message表
mysql> create table message (message varchar(50));
Query OK, 0 rows affected (0.01 sec)

# 查看message表结构
mysql> show create table message;
+---------+------------------------------------------------------------------------------------------------------+
| Table   | Create Table                                                                                         |
+---------+------------------------------------------------------------------------------------------------------+
| message | CREATE TABLE `message` (
  `message` varchar(50) DEFAULT NULL
) ENGINE=InnoDB DEFAULT CHARSET=latin1 |
+---------+------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)

插入数据

# 插入
mysql> insert into message value("hello chenby");
Query OK, 1 row affected (0.00 sec)

# 查看
mysql> select * from message;
+---------------+
| message       |
+---------------+
| hello chenby |
+---------------+
1 row in set (0.00 sec)

四、测试备库

连接mysql-1

 mysql -h mysql-1.mysql
Welcome to the MySQL monitor.  Commands end with ; or \g.
Your MySQL connection id is 362
Server version: 5.7.38 MySQL Community Server (GPL)

Copyright (c) 2000, 2022, Oracle and/or its affiliates.

Oracle is a registered trademark of Oracle Corporation and/or its
affiliates. Other names may be trademarks of their respective
owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

mysql>
mysql>

查看库、表结构

# 查看数据库列表
mysql> show databases;
+------------------------+
| Database               |
+------------------------+
| information_schema     |
| cby                    |
| mysql                  |
| performance_schema     |
| sys                    |
| test                   |
| xtrabackup_backupfiles |
+------------------------+
7 rows in set (0.01 sec)

# 使用cby库
mysql> use cby;
Reading table information for completion of table and column names
You can turn off this feature to get a quicker startup with -A

Database changed
mysql>

# 查看表列表
mysql> show tables;
+---------------+
| Tables_in_cby |
+---------------+
| message       |
+---------------+
1 row in set (0.00 sec)

# 查看message表结构
mysql> show create table message;
+---------+------------------------------------------------------------------------------------------------------+
| Table   | Create Table                                                                                         |
+---------+------------------------------------------------------------------------------------------------------+
| message | CREATE TABLE `message` (
  `message` varchar(50) DEFAULT NULL
) ENGINE=InnoDB DEFAULT CHARSET=latin1 |
+---------+------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)

mysql>

# 查询数据
mysql> select * from message;
+---------------+
| message       |
+---------------+
| hello chenby |
+---------------+
1 row in set (0.00 sec)

mysql>

# 写入数据
mysql> insert into message values("hello world");
ERROR 1290 (HY000): The MySQL server is running with the --super-read-only option so it cannot execute this statement
mysql>
# 这是因为mysql-1是一个只读备库，无法进行写操作。

五、测试mysql-read服务

循环中运行

kubectl run mysql-client-loop --image=mysql:5.7 -i -t --rm --restart=Never --\
>   bash -ic "while sleep 1; do mysql -h mysql-read -e 'SELECT @@server_id,NOW()'; done"
If you don't see a command prompt, try pressing enter.
+-------------+---------------------+
| @@server_id | NOW()               |
+-------------+---------------------+
|         102 | 2022-06-07 09:52:19 |
+-------------+---------------------+
+-------------+---------------------+
| @@server_id | NOW()               |
+-------------+---------------------+
|         101 | 2022-06-07 09:52:20 |
+-------------+---------------------+
+-------------+---------------------+
| @@server_id | NOW()               |
+-------------+---------------------+
|         100 | 2022-06-07 09:52:21 |
+-------------+---------------------+

六、扩缩容

# 扩容至5副本
kubectl scale statefulset mysql  --replicas=5

# 查看扩容过程
kubectl get pods --watch
mysql-3                                   0/2     Pending             0             0s
mysql-3                                   0/2     Pending             0             1s
mysql-3                                   0/2     Pending             0             2s
mysql-3                                   0/2     Init:0/2            0             2s
mysql-3                                   0/2     Init:0/2            0             2s
mysql-3                                   0/2     Init:0/2            0             3s
mysql-3                                   0/2     Init:1/2            0             4s
mysql-3                                   0/2     Init:1/2            0             5s
mysql-3                                   0/2     PodInitializing     0             12s
mysql-3                                   1/2     Error               0             13s
mysql-3                                   1/2     Running             1 (2s ago)    14s
mysql-3                                   2/2     Running             1 (6s ago)    18s
mysql-4                                   0/2     Pending             0             0s
mysql-4                                   0/2     Pending             0             0s
mysql-4                                   0/2     Pending             0             2s
mysql-4                                   0/2     Init:0/2            0             2s
mysql-4                                   0/2     Init:0/2            0             2s
mysql-4                                   0/2     Init:1/2            0             3s
mysql-4                                   0/2     Init:1/2            0             4s
mysql-4                                   0/2     PodInitializing     0             12s
mysql-4                                   1/2     Error               0             13s
mysql-4                                   1/2     Running             1 (1s ago)    14s
mysql-4                                   2/2     Running             1 (7s ago)    20s


# 缩容只2副本
kubectl scale statefulset mysql  --replicas=2

# 查看缩容过程
kubectl get pods --watch
mysql-4                                   2/2     Terminating         1 (74s ago)   87s
mysql-4                                   2/2     Terminating         1 (104s ago)   117s
mysql-4                                   0/2     Terminating         1              118s
mysql-4                                   0/2     Terminating         1              118s
mysql-4                                   0/2     Terminating         1              118s
mysql-3                                   2/2     Terminating         1 (2m4s ago)   2m16s
mysql-3                                   2/2     Terminating         1 (2m34s ago)   2m46s
mysql-3                                   0/2     Terminating         1               2m47s
mysql-3                                   0/2     Terminating         1               2m47s
mysql-3                                   0/2     Terminating         1               2m47s
mysql-2                                   2/2     Terminating         0               16m
mysql-2                                   2/2     Terminating         0               16m
mysql-2                                   0/2     Terminating         0               16m
mysql-2                                   0/2     Terminating         0               16m
mysql-2                                   0/2     Terminating         0               16m

https://www.oiox.cn/
https://www.chenby.cn/
https://cby-chen.github.io/
https://blog.csdn.net/qq_3392...
https://my.oschina.net/u/3981543
https://www.zhihu.com/people/...
https://segmentfault.com/u/hp...
https://juejin.cn/user/331578...
https://cloud.tencent.com/dev...
https://www.jianshu.com/u/0f8...
https://www.toutiao.com/c/use...
CSDN、GitHub、知乎、开源中国、思否、掘金、简书、腾讯云、今日头条、个人博客、全网可搜《小陈运维》
文章主要发布于微信公众号：《Linux运维交流社区》
