Docker 部署中间件

本篇文章给大家分享《Docker 部署中间件》，覆盖了数据库的常见基础知识，其实一个语言的全部知识点一篇文章是不可能说完的，但希望通过这些问题，让读者对自己的掌握程度有一定的认识(B 数)，从而弥补自己的不足，更好的掌握它。

Docker 安装

1. 卸载旧版本

sudo yum remove docker \
    docker-client \
    docker-client-latest \
    docker-common \
    docker-latest \
    docker-latest-logrotate \
    docker-logrotate \
    docker-engine

2. 安装基础依赖

yum install -y yum-utils device-mapper-persistent-data lvm2

3. 配置 docker yum 源

sudo yum-config-manager --add-repo http://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo

4. 安装并启动 docker

yum install -y docker-ce-19.03.8 docker-ce-cli-19.03.8 containerd.io

systemctl enable docker
systemctl start docker

5. 查看 docker 版本

docker --version

6. 配置 docker 加速

sudo mkdir -p /etc/docker
sudo tee /etc/docker/daemon.json

7. 设置开机自启动

sudo systemctl daemon-reload
sudo systemctl restart docker

Docker-Compose 安装

1. 安装

sudo curl -L https://github.com/docker/compose/releases/download/1.25.5/docker-compose-`uname -s`-`uname -m` > /usr/local/bin/docker-compose

sudo chmod +x /usr/local/bin/docker-compose

2. 查看版本

docker-compose --version

Docker 部署 Nginx

1. 拉取镜像

docker pull nginx:1.20

2. 运行容器

docker run --name nginx -d -p 80:80 nginx:1.20

3. 进入容器内部

docker exec -it nginx bash

4. 拷贝配置文件

docker cp nginx:/etc/nginx /data/software/docker/nginx/

5. 配置文件

user  nginx;
worker_processes  auto;

error_log  /var/log/nginx/error.log notice;
pid        /var/run/nginx.pid;


events {
    worker_connections  1024;
}


http {
    include       /etc/nginx/mime.types;
    default_type  application/octet-stream;

    log_format  main  '$remote_addr - $remote_user [$time_local] "$request" '
                      '$status $body_bytes_sent "$http_referer" '
                      '"$http_user_agent" "$http_x_forwarded_for"';

    access_log  /var/log/nginx/access.log  main;

    sendfile        on;
    #tcp_nopush     on;

    keepalive_timeout  65;

    #gzip  on;

    include /etc/nginx/conf.d/*.conf;
}

6. 数据卷挂载

docker run --name nginx -v /data/software/docker/nginx/conf:/etc/nginx -v /data/software/docker/nginx/data:/usr/share/nginx -v /data/software/docker/nginx/log:/var/log/nginx -p 80:80 -d nginx:1.20

命令说明：

• 挂载配置文件

  -v /data/software/docker/nginx/conf:/etc/nginx

• 挂载数据

  -v /data/software/docker/nginx/data:/usr/share/nginx

• 挂载日志文件

  -v /data/software/docker/nginx/log:/var/log/nginx

Docker 部署 MySQL

1. 拉取镜像

docker pull mysql:5.7

2. 运行容器

docker run --name mysql -d -e MYSQL_ROOT_PASSWORD=123456 mysql:5.7

3. 进入容器内部

docker exec -it mysql bash

4. 拷贝配置文件

docker cp mysql:/etc/mysql/mysql.conf.d /data/software/docker/mysql/conf/

5. 配置文件

[mysqld]
pid-file        = /var/run/mysqld/mysqld.pid
socket          = /var/run/mysqld/mysqld.sock
datadir         = /var/lib/mysql
log-error       = /var/log/mysql/error.log
# By default we only accept connections from localhost
bind-address    = 0.0.0.0
# Disabling symbolic-links is recommended to prevent assorted security risks
symbolic-links=0

6. 数据卷挂载

docker run --name mysql -d -v /data/software/docker/mysql/conf:/etc/mysql/conf.d -v /data/software/docker/mysql/data:/var/lib/mysql -v /data/software/docker/mysql/log:/var/log/mysql -p 3306:3306 -e MYSQL_ROOT_PASSWORD=123456 mysql:5.7

命令说明：

• 挂载配置文件

  -v /data/software/docker/mysql/conf:/etc/mysql/conf.d

• 挂载数据

  -v /data/software/docker/mysql/data:/var/lib/mysql

• 挂载日志文件

  -v /data/software/docker/mysql/log:/var/log/mysql

  注意：

  chmod 777 /data/software/docker/mysql/log/

• 指定root用户命令

  -e MYSQL_ROOT_PASSWORD=123456

Docker 部署 Redis

1. 拉取镜像

docker pull redis:6.2.6

2. 运行容器

docker run --name redis -d -p 6379:6379  redis:6.2.6

3. 进入容器内部

docker exec -it redis bash

4. 配置文件

port 6379
bind 0.0.0.0
requirepass 123456
daemonize no
pidfile /var/run/redis_6379.pid
logfile "/var/log/redis.log"
dbfilename dump.rdb
dir /data/
databases 16
appendonly yes
appendfilename "appendonly.aof"
# appendfsync always
appendfsync everysec
# appendfsync no

5. 数据卷挂载

docker run --name redis -d -p 6379:6379 -v /data/software/docker/redis/conf:/usr/local/etc/redis -v /data/software/docker/redis/data:/data -v /data/software/docker/redis/log:/var/log redis:6.2.6 redis-server /usr/local/etc/redis/redis.conf

命令说明：

• 挂载配置文件

  -v /data/software/docker/redis/conf:/usr/local/etc/redis

• 挂载数据

  -v /data/software/docker/redis/data:/data

• 挂载日志文件

   -v /data/software/docker/redis/log:/var/log/redis.log

  注意：

  chmod 777 /data/software/docker/redis/log/

• 指定配置文件

  redis-server /usr/local/etc/redis/redis.conf

6. Redis 客户端

1. 进入客户端

   docker exec -it redis redis-cli

2. 登录

   auth 123456

Docker 部署 MongoDB

1. 拉取镜像

docker pull mongo:5.0.8

2. 运行容器

docker run --name mongo -d -p 27017:27017 mongo:5.0.8

3. 进入容器内部

docker exec -it mongo bash

4. 拷贝配置文件

docker cp mongo:/etc/mongod.conf.orig /data/software/docker/mongo/conf/

5. 配置文件

# mongod.conf

# for documentation of all options, see:
#   https://www.mongodb.com/docs/manual/reference/configuration-options/

# Where and how to store data.
storage:
  dbPath: /data/db
  journal:
    enabled: true
#  engine:
#  wiredTiger:

# where to write logging data.
systemLog:
  destination: file
  logAppend: true
  path: /var/log/mongodb/mongod.log

# network interfaces
net:
  port: 27017
  bindIp: 0.0.0.0


# how the process runs
processManagement:
  timeZoneInfo: /usr/share/zoneinfo

#security:

#operationProfiling:

#replication:

#sharding:

## Enterprise-Only Options:

#auditLog:

#snmp:

6. 数据卷挂载

docker run --name mongo -d -v /data/software/docker/mongo/conf:/data/configdb -v /data/software/docker/mongo/data:/data/db -v /data/software/docker/mongo/log:/var/log/mongodb -p 27017:27017 mongo:5.0.8 --config /data/configdb/mongod.conf --auth

命令说明：

• 挂载配置文件

  -v /data/software/docker/mongo/conf:/data/configdb

• 挂载数据

  -v /data/software/docker/mongo/data:/data/db

• 挂载日志文件

  -v /data/software/docker/mongo/log:/var/log/mongodb

  注意：

  chmod 777 /data/software/docker/mongo/log/

• 指定配置文件

  --config /data/configdb/mongod.conf

• Mongo带验证

  --auth

7. MongoDB 操作

1. 进入mongo客户端

   docker exec -it mongo mongo

2. 进入

   use admin

3. 创建系统用户

   db.createUser({ user:'root',pwd:'123456',roles:[ { role:'userAdminAnyDatabase', db: 'admin'},"readWriteAnyDatabase"]});

4. 用户登录命令

   db.auth('root','123456');

5. 创建指定数据库用户命令

   db.createUser({user:"test",pwd:"123456",roles:[{role:'dbOwner',db:'test'}]})

Docker 部署 Zookeeper

1. 拉取镜像

docker pull zookeeper:3.6.3

2. 运行容器

docker run --name zookeeper -d -p 2181:2181 -p 2888:2888 -p 3888:3888 zookeeper:3.6.3

3. 进入容器内部

docker exec -it zookeeper bash

4. 拷贝配置文件

docker cp zookeeper:/conf/zoo.cfg /data/software/docker/zookeeper/conf/

5. 配置文件

dataDir=/data
dataLogDir=/datalog
tickTime=2000
initLimit=5
syncLimit=2
autopurge.snapRetainCount=3
autopurge.purgeInterval=0
maxClientCnxns=60
standaloneEnabled=false
admin.enableServer=false
server.1=localhost:2888:3888;2181

6. 数据卷挂载

docker run --name zookeeper -d -v /data/software/docker/zookeeper/conf:/conf -v /data/software/docker/zookeeper/data:/data -v /data/software/docker/zookeeper/log:/datalog -p 2181:2181 -p 2888:2888 -p 3888:3888 zookeeper:3.6.3

命令说明：

• 挂载配置文件

  -v /data/software/docker/zookeeper/conf:/conf

• 挂载数据

  -v /data/software/docker/zookeeper/data:/data

• 挂载日志文件

  -v /data/software/docker/zookeeper/log:/datalog

7. 客户端操作

1. 进入Zookeeper客户端

   docker exec -it zookeeper ./bin/zkCli.sh

Docker 部署 Kafka

1. 拉取镜像

docker pull bitnami/kafka:2.8.1

2. 运行容器

docker run --name kafka -d -e ALLOW_PLAINTEXT_LISTENER=yes  bitnami/kafka:2.8.1

3. 进入容器内部

docker exec -it kafka bash

4. 拷贝配置文件

docker cp kafka:/opt/bitnami/kafka/config /data/software/docker/kafka/conf/

5. 配置文件

############################# Server Basics #############################

# The id of the broker. This must be set to a unique integer for each broker.
broker.id=0

############################# Socket Server Settings #############################
listeners=PLAINTEXT://0.0.0.0:9092

# Hostname and port the broker will advertise to producers and consumers. If not set,
# it uses the value for "listeners" if configured.  Otherwise, it will use the value
# returned from java.net.InetAddress.getCanonicalHostName().
advertised.listeners=PLAINTEXT://ip:9092

# Maps listener names to security protocols, the default is for them to be the same. See the config documentation for more details
#listener.security.protocol.map=PLAINTEXT:PLAINTEXT,SSL:SSL,SASL_PLAINTEXT:SASL_PLAINTEXT,SASL_SSL:SASL_SSL

# The number of threads that the server uses for receiving requests from the network and sending responses to the network
num.network.threads=3

# The number of threads that the server uses for processing requests, which may include disk I/O
num.io.threads=8

# The send buffer (SO_SNDBUF) used by the socket server
socket.send.buffer.bytes=102400

# The receive buffer (SO_RCVBUF) used by the socket server
socket.receive.buffer.bytes=102400

# The maximum size of a request that the socket server will accept (protection against OOM)
socket.request.max.bytes=104857600


############################# Log Basics #############################

# A comma separated list of directories under which to store log files
log.dirs=/bitnami/kafka/data

# The default number of log partitions per topic. More partitions allow greater
# parallelism for consumption, but this will also result in more files across
# the brokers.
num.partitions=1

# The number of threads per data directory to be used for log recovery at startup and flushing at shutdown.
# This value is recommended to be increased for installations with data dirs located in RAID array.
num.recovery.threads.per.data.dir=1

############################# Internal Topic Settings  #############################
# The replication factor for the group metadata internal topics "__consumer_offsets" and "__transaction_state"
# For anything other than development testing, a value greater than 1 is recommended to ensure availability such as 3.
offsets.topic.replication.factor=1
transaction.state.log.replication.factor=1
transaction.state.log.min.isr=1


############################# Log Retention Policy #############################
# The minimum age of a log file to be eligible for deletion due to age
log.retention.hours=168

# A size-based retention policy for logs. Segments are pruned from the log unless the remaining
# segments drop below log.retention.bytes. Functions independently of log.retention.hours.
#log.retention.bytes=1073741824

# The maximum size of a log segment file. When this size is reached a new log segment will be created.
log.segment.bytes=1073741824

# The interval at which log segments are checked to see if they can be deleted according
# to the retention policies
log.retention.check.interval.ms=300000

############################# Zookeeper #############################
zookeeper.connect=ip:2181/kafka
# Timeout in ms for connecting to zookeeper
zookeeper.connection.timeout.ms=18000

group.initial.rebalance.delay.ms=0

auto.create.topics.enable=true

max.partition.fetch.bytes=1048576
max.request.size=1048576
sasl.enabled.mechanisms=PLAIN,SCRAM-SHA-256,SCRAM-SHA-512
sasl.mechanism.inter.broker.protocol=

6. 数据卷挂载

docker run --name kafka -d -v /data/software/docker/kafka/conf:/bitnami/kafka/config -v /data/software/docker/kafka/data:/bitnami/kafka/data -p 9092:9092 -e ALLOW_PLAINTEXT_LISTENER=yes bitnami/kafka:2.8.1

命令说明：

• 挂载配置文件

  -v /data/software/docker/kafka/conf:/bitnami/kafka/config

• 挂载数据

  -v /data/software/docker/kafka/data:/bitnami/kafka/data -p 9092:9092

  注意：

  chmod 777 /data/software/docker/kafka/data/

Docker 部署 RabbitMQ

1. 拉取镜像

docker pull rabbitmq:3.8-management

说明：镜像带management表示已经安装RabbitMQ后台管理插件。

2. 运行容器

docker run --name rabbitmq -d -p 5672:5672 -p 15672:15672 rabbitmq:3.8-management

3. 进入容器内部

docker exec -it rabbitmq bash

4. 拷贝配置文件

docker cp rabbitmq:/etc/rabbitmq /data/software/docker/rabbitmq/conf/

5. 配置文件

loopback_users.guest = false
listeners.tcp.default = 5672
management.tcp.port = 15672

6. 数据卷挂载

docker run --name rabbitmq -p 5672:5672 -p 15672:15672 -v /data/software/docker/rabbitmq/conf:/etc/rabbitmq -v /data/software/docker/rabbitmq/data:/var/lib/rabbitmq/mnesia -v /data/software/docker/rabbitmq/log:/var/log/rabbitmq/log -e RABBITMQ_DEFAULT_USER=guest -e RABBITMQ_DEFAULT_PASS=123456  -d rabbitmq:3.8-management

命令说明：

• 挂载配置文件

  -v /data/software/docker/rabbitmq/conf:/etc/rabbitmq

• 挂载数据

  -v /data/software/docker/rabbitmq/data:/var/lib/rabbitmq/mnesia

• 挂载日志文件

  -v /data/software/docker/rabbitmq/log:/var/log/rabbitmq/log

• 指定后台管理界面的登录用户名、密码

  -e RABBITMQ_DEFAULT_USER=guest -e RABBITMQ_DEFAULT_PASS=123456

Docker 部署 Elastic Search

安装Elastic Search

1. 拉取镜像

docker pull elasticsearch:6.8.22

2. 运行容器

docker run --name elasticsearch -d elasticsearch:6.8.22

启动报错：

[1]: max virtual memory areas vm.max_map_count [65530] is too low, increase to at least [262144]

解决方法：

1. 在centos虚拟机中，修改配置sysctl.conf

   vim /etc/sysctl.conf

2. 加入如下配置

   vm.max_map_count=262144

3. 启用配置

   sysctl -p

3. 进入容器内部

docker exec -it elasticsearch bash

4. 拷贝配置文件

docker cp elasticsearch:/usr/share/elasticsearch/config/ /data/software/docker/elasticsearch/conf/

5. 配置文件

cluster.name: "docker-cluster"
network.host: 0.0.0.0

说明：

注意指定

docker run --name elasticsearch -d -p 9200:9200 -p 9300:9300 -v /data/software/docker/elasticsearch/conf:/usr/share/elasticsearch/config -v /data/software/docker/elasticsearch/data:/usr/share/elasticsearch/data -v /data/software/docker/elasticsearch/log:/usr/share/elasticsearch/logs  elasticsearch:6.8.22

命令说明：

• 挂载配置文件

  -v /data/software/docker/elasticsearch/conf:/usr/share/elasticsearch/config

• 挂载数据

  -v /data/software/docker/elasticsearch/data:/usr/share/elasticsearch/data

• 挂载日志文件

  -v /data/software/docker/elasticsearch/log:/usr/share/elasticsearch/logs

  注意：

  chmod 777 /data/software/docker/elasticsearch/data/

  chmod 777 /data/software/docker/elasticsearch/log/

安装 Kibana

1. 拉取镜像

docker pull kibana:6.8.22

2. 运行容器

docker run -d --name kibana -e ELASTICSEARCH_URL=http://ip:9200 -p 5601:5601 kibana:6.8.22

3. 进入容器内部

docker exec -it kibana bash

4. 拷贝配置文件

docker cp kibana:/usr/share/kibana/config/ /data/software/docker/kibana/conf/

5. 配置文件

server.name: kibana
server.host: "0"
elasticsearch.hosts: [ "http://ip:9200" ]
xpack.monitoring.ui.container.elasticsearch.enabled: true

6. 数据卷挂载

docker run -d --name kibana -v /data/software/docker/kibana/conf:/usr/share/kibana/config -v /data/software/docker/kibana/data:/usr/share/kibana/data -p 5601:5601 kibana:6.8.22

命令说明：

• 挂载配置文件

   -v /data/software/docker/kibana/conf:/usr/share/kibana/config

• 挂载数据

   /data/software/docker/kibana/data:/usr/share/kibana/data

  注意：

  chmod 777 /data/software/docker/kibana/data/

文中关于mysql的知识介绍，希望对你的学习有所帮助！若是受益匪浅，那就动动鼠标收藏这篇《Docker 部署中间件》文章吧，也可关注golang学习网公众号了解相关技术文章。
