Go gRPC服务proto数据验证进阶教程
本篇文章主要是结合我之前面试的各种经历和实战开发中遇到的问题解决经验整理的,希望这篇《Go gRPC服务proto数据验证进阶教程》对你有很大帮助!欢迎收藏,分享给更多的需要的朋友学习~
创建proto文件,添加验证规则
这里使用第三方插件go-proto-validators自动生成验证规则。
go get github.com/mwitkow/go-proto-validators
1.新建simple.proto文件
syntax = "proto3"; package proto; import "github.com/mwitkow/go-proto-validators/validator.proto"; message InnerMessage { // some_integer can only be in range (1, 100). int32 some_integer = 1 [(validator.field) = {int_gt: 0, int_lt: 100}]; // some_float can only be in range (0;1). double some_float = 2 [(validator.field) = {float_gte: 0, float_lte: 1}]; } message OuterMessage { // important_string must be a lowercase alpha-numeric of 5 to 30 characters (RE2 syntax). string important_string = 1 [(validator.field) = {regex: "^[a-z]{2,5}$"}]; // proto3 doesn't have `required`, the `msg_exist` enforces presence of InnerMessage. InnerMessage inner = 2 [(validator.field) = {msg_exists : true}]; } service Simple{ rpc Route (InnerMessage) returns (OuterMessage){}; }
代码import "github.com/mwitkow/go-proto-validators/validator.proto",文件validator.proto需要import "google/protobuf/descriptor.proto";包,不然会报错。
google/protobuf地址:
https://github.com/protocolbuffers/protobuf/blob/main/src/google/protobuf/descriptor.proto
把src文件夹中的protobuf目录下载到GOPATH目录下。
2.编译simple.proto文件
go get github.com/mwitkow/go-proto-validators/protoc-gen-govalidators
指令编译:
protoc --govalidators_out=. --go_out=plugins=grpc:./ ./simple.proto
或者使用VSCode-proto3插件,第一篇有介绍。只需要添加"--govalidators_out=."即可。
// vscode-proto3插件配置 "protoc": { // protoc.exe所在目录 "path": "C:\\Go\\bin\\protoc.exe", // 保存时自动编译 "compile_on_save": true, "options": [ // go编译输出指令 "--go_out=plugins=grpc:.", "--govalidators_out=." ] },
编译完成后,自动生成simple.pb.go和simple.validator.pb.go文件,simple.pb.go文件不再介绍,我们看下simple.validator.pb.go文件。
// Code generated by protoc-gen-gogo. DO NOT EDIT. // source: go-grpc-example/9-grpc_proto_validators/proto/simple.proto package proto import ( fmt "fmt" math "math" proto "github.com/golang/protobuf/proto" _ "github.com/mwitkow/go-proto-validators" regexp "regexp" github_com_mwitkow_go_proto_validators "github.com/mwitkow/go-proto-validators" ) // Reference imports to suppress errors if they are not otherwise used. var _ = proto.Marshal var _ = fmt.Errorf var _ = math.Inf func (this *InnerMessage) Validate() error { if !(this.SomeInteger > 0) { return github_com_mwitkow_go_proto_validators.FieldError("SomeInteger", fmt.Errorf(`value '%v' must be greater than '0'`, this.SomeInteger)) } if !(this.SomeInteger = 0) { return github_com_mwitkow_go_proto_validators.FieldError("SomeFloat", fmt.Errorf(`value '%v' must be greater than or equal to '0'`, this.SomeFloat)) } if !(this.SomeFloat <p>里面自动生成了message中属性的验证规则。</p> <h3>把grpc_validator验证拦截器添加到服务端</h3> <pre class="brush:go;">grpcServer := grpc.NewServer(cred.TLSInterceptor(), grpc.StreamInterceptor(grpc_middleware.ChainStreamServer( grpc_validator.StreamServerInterceptor(), grpc_auth.StreamServerInterceptor(auth.AuthInterceptor), grpc_zap.StreamServerInterceptor(zap.ZapInterceptor()), grpc_recovery.StreamServerInterceptor(recovery.RecoveryInterceptor()), )), grpc.UnaryInterceptor(grpc_middleware.ChainUnaryServer( grpc_validator.UnaryServerInterceptor(), grpc_auth.UnaryServerInterceptor(auth.AuthInterceptor), grpc_zap.UnaryServerInterceptor(zap.ZapInterceptor()), grpc_recovery.UnaryServerInterceptor(recovery.RecoveryInterceptor()), )), )
运行后,当输入数据验证失败后,会有以下错误返回
Call Route err: rpc error: code = InvalidArgument desc = invalid field SomeInteger: value '101' must be less than '100'
其他类型验证规则设置
enum验证
syntax = "proto3"; package proto; import "github.com/mwitkow/go-proto-validators/validator.proto"; message SomeMsg { Action do = 1 [(validator.field) = {is_in_enum : true}]; } enum Action { ALLOW = 0; DENY = 1; CHILL = 2; }
UUID验证
syntax = "proto3"; package proto; import "github.com/mwitkow/go-proto-validators/validator.proto"; message UUIDMsg { // user_id must be a valid version 4 UUID. string user_id = 1 [(validator.field) = {uuid_ver: 4, string_not_empty: true}]; }
总结
go-grpc-middleware中grpc_validator集成go-proto-validators,我们只需要在编写proto时设好验证规则,并把grpc_validator添加到gRPC服务端,就能完成gRPC的数据验证,很简单也很方便。
教程源码地址:https://github.com/Bingjian-Zhu/go-grpc-example
今天关于《Go gRPC服务proto数据验证进阶教程》的内容介绍就到此结束,如果有什么疑问或者建议,可以在golang学习网公众号下多多回复交流;文中若有不正之处,也希望回复留言以告知!
