向 X509v3 授权密钥标识符添加 DirName 和序列号的方法

来源：stackoverflow 2024-02-10 16:18:24 0浏览收藏

本篇文章主要是结合我之前面试的各种经历和实战开发中遇到的问题解决经验整理的，希望这篇《向 X509v3 授权密钥标识符添加 DirName 和序列号的方法》对你有很大帮助！欢迎收藏，分享给更多的需要的朋友学习~

问题内容

我正在尝试使用 openssl 和 go 代码生成客户端证书。我有一个 openssl 脚本，可以生成具有所需扩展名的证书，并且我想使用 go 代码实现相同的结果。

使用 openssl

选项.ext

openssl 使用的 options.ext 文件包含以下扩展名：

basicconstraints=ca:false
authoritykeyidentifier=keyid,issuer
subjectkeyidentifier=hash
keyusage=digitalsignature
extendedkeyusage=clientauth

生成-client-cert.sh

我目前拥有的openssl脚本如下：

openssl req \
  -newkey rsa:2048 \
  -keyout cert.crt \
  -out cert.csr \
  -nodes \
  -sha256

openssl x509 \
  -req \
  -ca ca.crt \
  -cakey ca.key \
  -in cert.csr \
  -out cert.crt \
  -days 365 \
  -cacreateserial \
  -extfile options.ext \
  -sha256

生成证书后，我可以使用以下命令查看其详细信息：

openssl x509 -in cert.crt -text -noout

生成的证书具有以下结构：

certificate:
    data:
        version: 3 (0x2)
        serial number:
            xx:xx:xx:xx:xx:xx:xx:xx
    signature algorithm: sha256withrsaencryption
        issuer: cn=xxx
        validity
            not before: jan 1 00:00:00 2023 gmt
            not after : jan 1 00:00:00 2024 gmt
        subject: cn=xxx
        subject public key info:
            public key algorithm: rsaencryption
                rsa public-key: (2048 bit)
                modulus:
                    ...
                exponent: 65537 (0x10001)
        x509v3 extensions:
            x509v3 basic constraints:
                ca:false
            x509v3 authority key identifier:
                dirname:cn=xxx
                serial:xx:xx:xx:xx:xx:xx:xx:xx

            x509v3 subject key identifier:
                ...
            x509v3 key usage:
                digital signature
            x509v3 extended key usage:
                tls web client authentication
    signature algorithm: sha256withrsaencryption

它应该看起来像这样：

x509v3 authority key identifier:
    dirname:cn=xxx
    serial:xx:xx:xx:xx:xx:xx:xx:xx

执行代码

在我的 go 代码中，我使用 x509 包来生成证书。但是，我不确定如何设置 x509v3 授权密钥标识符扩展。这是我的 go 代码的相关部分：

import (
    "crypto/rand"
    "crypto/rsa"
    "crypto/sha1"
    "crypto/x509"
    "crypto/x509/pkix"
    "encoding/asn1"
    "os"
    "time"
)

...

var cacertificate *x509.certificate
var caprivatekey *rsa.privatekey

var authoritykeyidentifiervalue []byte // how to write this?

template := &x509.certificate{
    subject: pkix.name{
        commonname: "xxx",
    },
    extraextensions: []pkix.extension{
        {
            id:    asn1.objectidentifier{2, 5, 29, 35},
            value: authoritykeyidentifiervalue,
        },
    },
    keyusage:              x509.keyusagedigitalsignature,
    extkeyusage:           []x509.extkeyusage{x509.extkeyusageclientauth},
    notbefore:             time.now(),
    notafter:              time.now().adddate(0, 0, 365),
    isca:                  false,
    basicconstraintsvalid: true,
}

privatekey, err := rsa.generatekey(rand.reader, 2048)
if err != nil {
    // err
}

certificatebytes, err := x509.createcertificate(rand.reader, template, cacertificate, &privatekey.publickey, caprivatekey)
if err != nil {
    // err
}

// out

如何将 dirname 和序列号添加到 x509v3 授权密钥标识符？

正确答案

authoritykeyidentifiervalue 可以使用 asn1.marshal 生成。下面的演示根据 rfc 5280定义了 struct authkeyid > 并使用此结构生成值：

package main

import (
    "crypto/x509"
    "crypto/x509/pkix"
    "encoding/asn1"
    "encoding/hex"
    "encoding/pem"
    "fmt"
    "math/big"
)

// rfc 5280, a.2. implicitly tagged module, 1988 syntax
//
//  authoritykeyidentifier ::= sequence {
//      keyidentifier             [0] keyidentifier            optional,
//      authoritycertissuer       [1] generalnames             optional,
//      authoritycertserialnumber [2] certificateserialnumber  optional }
//      -- authoritycertissuer and authoritycertserialnumber must both
//      -- be present or both be absent
type authkeyid struct {
    keyidentifier             []byte       `asn1:"optional,tag:0"`
    authoritycertissuer       generalnames `asn1:"optional,tag:1"`
    authoritycertserialnumber *big.int     `asn1:"optional,tag:2"`
}

// rfc 5280, a.2. implicitly tagged module, 1988 syntax
//
//  generalnames ::= sequence size (1..max) of generalname
//
//  generalname ::= choice {
//       othername                 [0]  anothername,
//       rfc822name                [1]  ia5string,
//       dnsname                   [2]  ia5string,
//       x400address               [3]  oraddress,
//       directoryname             [4]  name,
//       edipartyname              [5]  edipartyname,
//       uniformresourceidentifier [6]  ia5string,
//       ipaddress                 [7]  octet string,
//       registeredid              [8]  object identifier }
type generalnames struct {
    name []pkix.rdnsequence `asn1:"tag:4"`
}

func gen(issuer *x509.certificate) ([]byte, error) {
    return asn1.marshal(authkeyid{
        keyidentifier:             issuer.subjectkeyid,
        authoritycertissuer:       generalnames{name: []pkix.rdnsequence{issuer.issuer.tordnsequence()}},
        authoritycertserialnumber: issuer.serialnumber,
    })
}

func main() {
    cacert := `-----begin certificate-----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-----end certificate-----`
    b, _ := pem.decode([]byte(cacert))
    if b == nil {
        panic("couldn't decode test certificate")
    }
    issuer, err := x509.parsecertificate(b.bytes)
    if err != nil {
        panic(err)
    }

    authoritykeyidentifiervalue, err := gen(issuer)
    if err != nil {
        panic(err)
    }
    fmt.println(hex.encodetostring(authoritykeyidentifiervalue))
}

十六进制编码值为：

30548014e58e3c0c9f7a2d05958774bf68d27fe921b2fe3ea12aa4283026310f300d060355040a13064d79204f7267311330110603550403130a4d7920526f6f7420434182101a80a30c937563aac65846d75bc57c30

十六进制字符串可以使用诸如 asn.1 javascript 解码器：

以下 c# 演示给出相同的结果：

using system.security.cryptography.x509certificates;
using system.text;

internal class program
{
    private static void main(string[] args)
    {
        var certbytes = encoding.ascii.getbytes(@"-----begin certificate-----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-----end certificate-----");

        using var issuer = new x509certificate2(certbytes);
        var e = x509authoritykeyidentifierextension.createfromcertificate(issuer, true, true);
        console.writeline(bytearraytohex(e.rawdata));
    }

    private static string bytearraytohex(byte[] bytes)
    {
        var builder = new stringbuilder(bytes.length * 2);

        for (int i = 0; i < bytes.length; i++)
        {
            builder.append($"{bytes[i]:x2}");
        }

        return builder.tostring();
    }
}

更新：

这是 gen 的更新版本，其中包含电子邮件地址：

func gen(issuer *x509.Certificate) ([]byte, error) {
    rdnSequence := issuer.Issuer.ToRDNSequence()
    if len(issuer.EmailAddresses) > 0 {
        oidEmail := asn1.ObjectIdentifier{1, 2, 840, 113549, 1, 9, 1}
        emails := make([]pkix.AttributeTypeAndValue, len(issuer.EmailAddresses))
        for i, value := range issuer.EmailAddresses {
            emails[i].Type = oidEmail
            emails[i].Value = value
        }
        rdnSequence = append(rdnSequence, emails)
    }

    return asn1.Marshal(authKeyId{
        KeyIdentifier:             issuer.SubjectKeyId,
        AuthorityCertIssuer:       generalNames{Name: []pkix.RDNSequence{rdnSequence}},
        AuthorityCertSerialNumber: issuer.SerialNumber,
    })
}

请注意，oid 已弃用（请参阅 http://oid- info.com/get/1.2.840.113549.1.9.1）。 .net 也不包含它。
