简介常见的7种Java设计模式

2023-12-23 12:19:14 0浏览收藏

对于一个文章开发者来说，牢固扎实的基础是十分重要的，golang学习网就来带大家一点点的掌握基础知识点。今天本篇文章带大家了解《简介常见的7种Java设计模式》，主要介绍了，希望对大家的知识积累有所帮助，快点收藏起来吧，否则需要时就找不到了！

了解Java设计模式：常用的7种设计模式简介，需要具体代码示例

Java设计模式是一种解决软件设计问题的通用解决方案，它提供了一套被广泛接受的设计思想与行为准则。设计模式帮助我们更好地组织和规划代码结构，使得代码具有更好的可维护性、可读性和可扩展性。在本文中，我们将介绍Java中常用的7种设计模式，并提供相应的代码示例。

单例模式（Singleton Pattern）：
单例模式保证一个类只有一个实例，并提供一个全局访问点。这在需要共享资源或限制对象个数的场景中非常有用。下面是一个单例模式的代码示例：

public class Singleton {

    private static Singleton instance;

    private Singleton() {
        // 私有构造函数，防止外部实例化
    }

    public static Singleton getInstance() {
        if (instance == null) {
            synchronized (Singleton.class) {
                if (instance == null) {
                    instance = new Singleton();
                }
            }
        }
        return instance;
    }
}

工厂模式（Factory Pattern）：
工厂模式通过一个工厂类来创建对象，封装了对象的创建过程。这可以隐藏对象的具体实现细节，使得客户端的代码更加简洁和可扩展。下面是一个工厂模式的代码示例：

public interface Shape {
    void draw();
}

public class Circle implements Shape {
    @Override
    public void draw() {
        System.out.println("Circle::draw()");
    }
}

public class Rectangle implements Shape {
    @Override
    public void draw() {
        System.out.println("Rectangle::draw()");
    }
}

public class ShapeFactory {
    public Shape getShape(String shapeType) {
        if (shapeType == null) {
            return null;
        }
        if (shapeType.equalsIgnoreCase("CIRCLE")) {
            return new Circle();
        } else if (shapeType.equalsIgnoreCase("RECTANGLE")) {
            return new Rectangle();
        }
        return null;
    }
}

观察者模式（Observer Pattern）：
观察者模式定义了一种一对多的依赖关系，当一个对象的状态发生变化时，依赖于它的其他对象将自动更新。这在事件驱动、发布-订阅，以及GUI开发中非常有用。下面是一个观察者模式的代码示例：

import java.util.ArrayList;
import java.util.List;

public class Subject {
    private List observers = new ArrayList<>();
    private int state;

    public int getState() {
        return state;
    }

    public void setState(int state) {
        this.state = state;
        notifyAllObservers();
    }

    public void attach(Observer observer) {
        observers.add(observer);
    }

    public void notifyAllObservers() {
        for (Observer observer : observers) {
            observer.update();
        }
    }
}

public abstract class Observer {
    protected Subject subject;
    public abstract void update();
}

public class BinaryObserver extends Observer {
    public BinaryObserver(Subject subject) {
        this.subject = subject;
        this.subject.attach(this);
    }

    public void update() {
        System.out.println("Binary String: " + Integer.toBinaryString(subject.getState()));
    }
}

public class OctalObserver extends Observer {
    public OctalObserver(Subject subject) {
        this.subject = subject;
        this.subject.attach(this);
    }

    public void update() {
        System.out.println("Octal String: " + Integer.toOctalString(subject.getState()));
    }
}

public class HexObserver extends Observer {
    public HexObserver(Subject subject) {
        this.subject = subject;
        this.subject.attach(this);
    }

    public void update() {
        System.out.println("Hex String: " + Integer.toHexString(subject.getState()));
    }
}

public class ObserverPatternDemo {
    public static void main(String[] args) {
        Subject subject = new Subject();
        new BinaryObserver(subject);
        new OctalObserver(subject);
        new HexObserver(subject);

        System.out.println("First state change: 15");
        subject.setState(15);
        System.out.println("Second state change: 10");
        subject.setState(10);
    }
}

建造者模式（Builder Pattern）：
建造者模式通过将对象的构建过程分离，使得相同的构建过程可用于创建不同的表示。这可以提高代码的灵活性和可读性，并且可以避免构建参数过多的问题。下面是一个建造者模式的代码示例：

public class Computer {
    private String cpu;
    private String memory;
    private String disk;
    // 省略其他属性和方法
}

public interface ComputerBuilder {
    ComputerBuilder setCpu(String cpu);
    ComputerBuilder setMemory(String memory);
    ComputerBuilder setDisk(String disk);
    Computer build();
}

public class BasicComputerBuilder implements ComputerBuilder {
    private Computer computer;

    public BasicComputerBuilder() {
        computer = new Computer();
    }

    public ComputerBuilder setCpu(String cpu) {
        computer.setCpu(cpu);
        return this;
    }

    public ComputerBuilder setMemory(String memory) {
        computer.setMemory(memory);
        return this;
    }

    public ComputerBuilder setDisk(String disk) {
        computer.setDisk(disk);
        return this;
    }

    public Computer build() {
        return computer;
    }
}

public class Director {
    private ComputerBuilder computerBuilder;

    public Director(ComputerBuilder computerBuilder) {
        this.computerBuilder = computerBuilder;
    }

    public Computer construct() {
        return computerBuilder
                .setCpu("i5")
                .setMemory("8GB")
                .setDisk("1TB")
                .build();
    }
}

public class BuilderPatternDemo {
    public static void main(String[] args) {
        ComputerBuilder computerBuilder = new BasicComputerBuilder();
        Director director = new Director(computerBuilder);
        Computer computer = director.construct();

        System.out.println(computer.toString());
    }
}

原型模式（Prototype Pattern）：
原型模式通过复制现有对象来创建新对象，而不是重新创建。这可以提高对象的创建效率，尤其是在对象的初始化过程比较复杂时。下面是一个原型模式的代码示例：

public abstract class Shape implements Cloneable {
    private String id;
    protected String type;

    abstract void draw();

    public String getId() {
        return id;
    }

    public void setId(String id) {
        this.id = id;
    }

    public Object clone() {
        Object clone = null;
        try {
            clone = super.clone();
        } catch (CloneNotSupportedException e) {
            e.printStackTrace();
        }
        return clone;
    }
}

public class Circle extends Shape {
    public Circle() {
        type = "Circle";
    }

    public void draw() {
        System.out.println("Inside Circle::draw() method.");
    }
}

public class Rectangle extends Shape {
    public Rectangle() {
        type = "Rectangle";
    }

    public void draw() {
        System.out.println("Inside Rectangle::draw() method.");
    }
}

public class ShapeCache {
    private static Map shapeMap = new HashMap<>();

    public static Shape getShape(String shapeId) {
        Shape cachedShape = shapeMap.get(shapeId);
        return (Shape) cachedShape.clone();
    }

    public static void loadCache() {
        Circle circle = new Circle();
        circle.setId("1");
        shapeMap.put(circle.getId(), circle);

        Rectangle rectangle = new Rectangle();
        rectangle.setId("2");
        shapeMap.put(rectangle.getId(), rectangle);
    }
}

public class PrototypePatternDemo {
    public static void main(String[] args) {
        ShapeCache.loadCache();

        Shape clonedShape1 = ShapeCache.getShape("1");
        System.out.println("Shape: " + clonedShape1.getType());

        Shape clonedShape2 = ShapeCache.getShape("2");
        System.out.println("Shape: " + clonedShape2.getType());
    }
}

适配器模式（Adapter Pattern）：
适配器模式将一个类的接口转换成客户端所期望的另一个接口。这可以在不改变现有代码的情况下，为不兼容的接口之间提供协同工作的能力。下面是一个适配器模式的代码示例：

public interface MediaPlayer {
    void play(String audioType, String fileName);
}

public interface AdvancedMediaPlayer {
    void playVlc(String fileName);

    void playMp4(String fileName);
}

public class VlcPlayer implements AdvancedMediaPlayer {
    public void playVlc(String fileName) {
        System.out.println("Playing vlc file. Name: " + fileName);
    }

    public void playMp4(String fileName) {
        // 空实现
    }
}

public class Mp4Player implements AdvancedMediaPlayer {
    public void playVlc(String fileName) {
        // 空实现
    }

    public void playMp4(String fileName) {
        System.out.println("Playing mp4 file. Name: " + fileName);
    }
}

public class MediaAdapter implements MediaPlayer {
    AdvancedMediaPlayer advancedMediaPlayer;

    public MediaAdapter(String audioType) {
        if (audioType.equalsIgnoreCase("vlc")) {
            advancedMediaPlayer = new VlcPlayer();
        } else if (audioType.equalsIgnoreCase("mp4")) {
            advancedMediaPlayer = new Mp4Player();
        }
    }

    public void play(String audioType, String fileName) {
        if (audioType.equalsIgnoreCase("vlc")) {
            advancedMediaPlayer.playVlc(fileName);
        } else if (audioType.equalsIgnoreCase("mp4")) {
            advancedMediaPlayer.playMp4(fileName);
        }
    }
}

public class AudioPlayer implements MediaPlayer {
    MediaAdapter mediaAdapter;

    public void play(String audioType, String fileName) {
        if (audioType.equalsIgnoreCase("mp3")) {
            System.out.println("Playing mp3 file. Name: " + fileName);
        } else if (audioType.equalsIgnoreCase("vlc") || audioType.equalsIgnoreCase("mp4")) {
            mediaAdapter = new MediaAdapter(audioType);
            mediaAdapter.play(audioType, fileName);
        } else {
            System.out.println("Invalid media. " + audioType + " format not supported");
        }
    }
}

public class AdapterPatternDemo {
    public static void main(String[] args) {
        AudioPlayer audioPlayer = new AudioPlayer();
        audioPlayer.play("mp3", "beyond_the_horizon.mp3");
        audioPlayer.play("mp4", "alone.mp4");
        audioPlayer.play("vlc", "far_far_away.vlc");
        audioPlayer.play("avi", "mind_me.avi");
    }
}

策略模式（Strategy Pattern）：
策略模式定义了一系列的算法，并将每个算法封装起来，使得它们可以互相替换。这样可以方便地切换算法或扩展新的算法，而不影响其他部分的代码。下面是一个策略模式的代码示例：

public interface Strategy {
    int doOperation(int num1, int num2);
}

public class OperationAdd implements Strategy {
    public int doOperation(int num1, int num2) {
        return num1 + num2;
    }
}

public class OperationSubtract implements Strategy {
    public int doOperation(int num1, int num2) {
        return num1 - num2;
    }
}

public class OperationMultiply implements Strategy {
    public int doOperation(int num1, int num2) {
        return num1 * num2;
    }
}

public class Context {
    private Strategy strategy;

    public Context(Strategy strategy) {
        this.strategy = strategy;
    }

    public int executeStrategy(int num1, int num2) {
        return strategy.doOperation(num1, num2);
    }
}

public class StrategyPatternDemo {
    public static void main(String[] args) {
        Context context = new Context(new OperationAdd());
        System.out.println("10 + 5 = " + context.executeStrategy(10, 5));

        context = new Context(new OperationSubtract());
        System.out.println("10 - 5 = " + context.executeStrategy(10, 5));

        context = new Context(new OperationMultiply());
        System.out.println("10 * 5 = " + context.executeStrategy(10, 5));
    }
}

通过以上示例代码，我们对Java中常用的7种设计模式进行了简单的介绍。每一种设计模式都有不同的场景和应用，它们可以在不同的项目中发挥作用。希望这篇文章可以帮助你了解并应用设计模式，并提升你的代码质量和开发效率。

今天关于《简介常见的7种Java设计模式》的内容就介绍到这里了，是不是学起来一目了然！想要了解更多关于java,设计模式,简介的内容请关注golang学习网公众号！
